NewBeeDrone AcroBee75 HD O3 BNF Drone – Compact, Lightweight, and High-Definition FPV Performance

The NewBeeDrone AcroBee75 HD O3 is the ultimate whoop for indoor HD FPV flying. As the lightest drone with a full DJI O3 unit, it offers exceptional agility and a flight time of up to 3.5 minutes. Powered by the G4 flight controller and built-in ELRS2.4 receiver, it’s perfectly tuned for smooth indoor flights in both self-level and acro modes. For the best footage, activate DJI RockSteady through your goggles.

Features:

Ultra-light with integrated DJI O3 HD system
G4 flight controller with ELRS2.4 receiver
Optimized for indoor FPV flying with 3.5 minutes flight time
Ready for Dshot600 and bi-directional Dshot
Expert-tuned for seamless flight performance

!!! Warning !!!

This drone is built exclusively with genuine NewBeeDrone components to ensure optimal performance and compatibility. Please note that using non-compatible parts from other brands may lead to technical issues. If you decide to modify the drone, you are fully responsible for any potential problems. We advise against modifications without proper expertise. Should any issues arise, avoid flashing the firmware. Instead, perform a factory reset through a configuration tool like Betaflight Configurator, followed by an accelerometer calibration. For additional help, reach out to our either us or the NewBeeDrone support team.

*Note: For outdoor flying, RockSteady is required in order to get the best picture quality(On DJI goggle Menu). The PID tune are base on the current setup. If you change any setting on the drone and it is acting weird, please flash the newest firmware.

NewBeeDrone AcroBee75 HD O3 BNF Drone Comparisioon

PRECAUTIONS:

This aircraft's PID tuning is based on the Tattu 450mAh 2S battery. Using other batteries may affect the flight experience.
Recording in air mode provides the best and highest quality footage.
Due to its small size, the aircraft's wind resistance is limited. It is designed for indoor flying, and its performance will be significantly affected during high winds.
This aircraft is suitable for cinematic FPV flying style and is not recommended for aggressive or freestyle flying.
If you receive a new aircraft with the DJI 03 Air Unit, you need to activate it yourself.
Any changes to the aircraft's PID or filter settings will affect its performance.
Modifying the aircraft's motors, propellers, or any hardware will impact its flight performance.
This aircraft is only suitable for short-range flights. Continually monitor the battery voltage during flight and ensure you have enough power for a safe return.
If you make any improper changes to the factory settings, you can restore them in BetaFlight.
The aircraft comes with the ELRS 3.0 version. Please ensure that your remote control is the same version. To pair, plug, and unplug the aircraft's power three times (via a tube).
Depending on your flying preferences, you can adjust the rate settings for a better flying experience.

DISCLAIMER:

Flying in certain areas is subject to specific regulations and restrictions.
You must comply with the laws and regulations of each region.
NewBeeDrone is not responsible for any hardware damage to the aircraft caused by modifying aircraft parts or self-adjusting configuration parameters.
This aircraft is suitable for individuals with certain FPV flying skills. It is different from DJI commercial drones and is a professional FPV drone used for filming, not a toy. We are not responsible for any damage to the aircraft caused by improper operation.

Specifications

Drone Size: 75mm
Flight Controller: BeeBrain HD G4 Flight Controller ExpressLRS (ELRS) 2.4G
Frame: Cockroach75 Brushless Frame
Motors: Flow 0804 12000kv Double Ball Bearing Brushless Motor
Propellers: Azi (Tri-Blade) Micro Propellers 40mm - 1.0mm Shaft
HD VTX & Camera: DJI O3 Air Unit
Canopy: NewBeeDrone Acrobee75 HD O3 Canopy
Total Weight without battery: 70.19g
Total Weight with battery: 98.24g - 99g
Recommended battery:
- Tattu 450mAh 7.6V High Voltage 95C 2S1P Lipo Battery Pack with XT30 Plug - Long Pack
- Tattu 650mAh 7.6V High Voltage 95C 2S1P Lipo Battery Pack with XT30 Plug - Long Pack
- Tattu 850mAh 7.6V High Voltage 95C 2S1P Lipo Battery Pack with XT30 Plug - Long Pack
- Tattu R-Line 550mAh 7.4V 95C 2S1P Lipo Battery Pack with XT30 Plug
MCU: STM32G474
VTX: DJI 03 Air Unit
ESC Firmware: z-h-40 - Bluejay 0.19.2 48kHz
ESC Specifications: 1 channel 20A ESC Double n-Mos
OSD: NBD OSD (Compatible with Betaflight OSD)
Flight Controller Weight: 7.22g (Including antenna and battery connector)
Flight Controller Size: Outer dimensions: 29 x 29 x 7.6mm
Flight Controller Holes: 25.5 x 25.5
Battery Input: 2S
UART1: TX & RX for DJI MSP + Displayport
UART2: TX & RX for EXPRESS LRS 3.0 Reciever
UART3: Free
UART4: SBUS on DJI Connector (RX only)
Total weight (w/o Battery) : Tracer 72.15g / CRSF 72.32g / ELRS 70.5g
Total Weight (with Battery): Tracer 100.35g / CRSF 100.52g / ELRS 98.7g
Prpeller: Gemfan 1609-4 40mm

BeeBrain BLV4 HD G4 Flight Controller ELRS2.4G Specifications:

MCU: STM32G474
ESC Firmware: Z-H-40 - Bluejay 0.19.2 48kHz.
ESC Specifications: 1 channel 20A ESC
Receiver: NBD ExpressLRS 3.0 Diversity (non-SPl)
Receiver Antenna: 1x BeeT-Antenna 1x 2.4G receiver antenna
Flight Controller Weight:7.4g (including antenna and XT30 Battery connector)
Flight Controller Size: Outer dimensions:29 x 29 x 7.6 mm
Flight Controller Holes: 25.5 x 25.5 mm
Battery Input: 1-2S
BEC:10V 2A for DJI O3 (under 2S power only)
BEC：5V 2A
UART1: Free
UART2: TX & RX for EXPRESSLRS 3.0 receiver
UART3: Free
UART4: Free
Flight time with Tattu 450mAh 2S battery is 3:00min (at 7v)

Includes:

1x NewBeeDrone AcroBee75 HD DJI O3 BNF
2x Extra HD Canopies
1x Extra Battery Strap (for other sized batteries)
4x Azi 40mm Propellers
1x NewBeeDrone AcroBee75 HD O3 Update Package
