COOLANOL silicate ester synthetic dielectric heat transfer fluids are designed to meet the special needs of sensitive electronic components and environmental control systems in aircraft, missiles and spacecraft. The proven quality and reliability of COOLANOL is an important additional safeguard against costly and potentially catastrophic failure of critical airborne electrical equipment.
COOLANOL is specifically intended for liquid circulating systems (dynamic liquid phase) found in high-density electronic packages in aerospace and military applications. Such systems are in wide use because of their excellent heat transfer efficiency. COOLANOL should not be used in vaporizing (boiling liquid) systems.
- Superb High and Low Temperature Stability
- Versatile and Simple to Handle
- Manufactured under Stringent Quality Control
- Oxidative Stability
- Radiation Resistance
MIL-C-47220B (May 1985) military specification, though inactive, distinguishes five fluid types. Fluid types III and IV represent products from the family of COOLANOL fluids, as shown in Table 1.
|MIL-C-47220B Fluid Type||Applicable Fluid|
|Type III||COOLANOL OS-59|
|Type IV||COOLANOL 25R|
Certain COOLANOL fluids relate to military contractor specifications as shown in Table 2
|OEM Specifications||Applicable Fluids|
|MMS-652, Rev A||COOLANOL 25R|
|Grumman GM 6003A, Amendment-No 1|
|Type I||COOLANOL 25R|
|Hughes Aircraft HMS 20-1458 Rev E||COOLANOL 25R|
|Northrop MS-138, Rev A||COOLANOL 25R|
