Alcoa Camloc - Stud Assembly, Turnlock Fastener | 26S8-5
Alcoa Camloc - Stud Assembly, Turnlock Fastener | 26S8-5
Hardware - Misc
26S8-5
Sale price
$6.13
Regular price
$7.66
Alcoa Camloc - Stud Assembly, Turnlock Fastener | 26S8-5
The Camloc 26S8-5 Stud is a phillips recess, fillister head fastener stud from the Calmoc 2600 series. Has a length of .880" and a total grip thickness of .150"-.179". These light-duty Camloc studs are rated for 200 pounds working strength (ultimate tensile strength 300 pounds). Made from steel with zinc plating.
Features
Product Type: Stud
Fastener Series: 2600
Stud Size: 5
Stud Type: Low Profile
Head Type: Phillips
Head Shape: Fillister
Body Material: Zinc Plated Steel
Total Stud Length: .880in [22.35mm]
Total Material Thickness
w/ fixed receptacle: .150-.179in [3.81-4.54mm]
w/ adjustable receptacle: .130-.490in [3.30-12.44mm]
Working Strength: 200 lbs
Ultimate Tensile Strength: 300 lbs
